Components

External Signal Interface

4-20mA analog signal to S-Link™

ESI-1 is an External Signal Interface to the S-link bus. It has two 4-20mA analogue inputs that control the bow and stern thrusters proportionally.

It can operate all E, SEP, SH and SAC series thrusters, including retractable thrusters and Automatic Main Switch (AMS).

The ESI-1 is typically used with autopilots with 4-20mA outputs and 3rd party control systems.

Properties

S-Link™ is a CAN-based control system used for communication between Sleipner products installed on a vessel.

Compact and waterproof plugs
Keyed and color-coded connectors to ensure correct and easy installation
Different cable lengths, extenders and T-connectors makes the system scalable and flexible to install

Weight	Value
Net weight	0.5kg / lbs

Electrical Data Matrix	Value
Recommended fuse	5 A

Ideal vessel integration	Value
Typical vessel class	Commercial vessel, Motor boat, Sail boat

Ignition Protection rating	Value
Ignition Protection rating	IP20

Product Features	Value
S-Link	Yes
Safe Start-Up	No

Temperature	Value
Operating temperature*	–20°C to +70°C [–4°F to +158°F]

Temperature control	Value
Environmental room ambient temperature	–40°C to +85°C [–40°F to +176°F]
